M502N

Displacement (cc): 486
Type: 2-cylinder/4-stroke/8-valve
Bore x Stroke (mm): ø68×67
Power (hp/rpm): 46.94kW  8500r/min
Max. torque: 45.0N·m/6750 r/min
Compression ratio: 10.7:1
Fuel system: Bosch EFI
Valve train: DOHC
Ignition: TCI
Starter: Electric
Lubrication system: Pressure splash lubrication
Cooling system: Liquid- cooled

Gear shifting type: 6-speed
Transmission Type: Chain
Clutch type: Wet multi-plate

Frame: Diamond
Front wheel: Aluminum alloy
Front suspension: Upside-down telescopic forks
Front suspension travel (mm): 119.5
Front tyre: Pirelli Angel GT 120/70-ZR17
Rear wheel: Aluminum Alloy
Rear suspension:Pro-link Mono shock- absorber ,adjustable
Rear suspension travel (mm): 55
Rear tyre: Pirelli Angel GT 160/60 ZR17
Front brake: Disc with ABS system
Front brakes diameter (mm): 300
Rear brake:Disc with ABS system
Rear brakes diameter (mm): 240

Curb weight (kg): 208
Seat height (mm): 790
Overall length (mm): 2145
Overall width (mm): 775
Overall height(mm): 1100
Ground clearance (mm): 165
Wheelbase (mm): 1420
Fuel capacity (L): 17
Top speed (km/h): 160
Max. load (kg): 185
Battery: 12V8Ah , maintenance free
